Name: MICROTEK SMU 3024
SKU: 1255
Availability: InStock

Sale!

MICROTEK SMU 3024

Original price was: ₹5,190.00.Current price is: ₹4,671.00.

- - Weight1.4kg
  - Output Voltage24VDC
  - Dimensions (L*W*H)21x16x8.3
SALIENT FEATURES:

Highly Efficient PWM Charging, ensures More Battery Life and Improved Solar System Performance.

Automatically recognizes Day & Night.

Mosfet Switching System.

Micro Controller based design.

Priority Load Sharing through Solar during daytime, thereby saving your mains electricity.
Description

Additional Information

Technical Specifications

Categories: MICROTEK SMU 3024, Microtek solar all products Tags: 1 to 10 kW, 2335VA, 535 Watt / 24V DCR Bi-Facial, Microtek 1kVA/24V MPPT, Microtek 390 W 24 V Mono Perc Solar Panel, Microtek 535 Watt / 24V DCR Bi-Facial, Microtek 535 Watt / 24V DCR Mono Facial, Microtek 545 Watt / 24V Non-DCR, Microtek 550 Watt / 24V Non-DCR Bifacial, Microtek 8070 96V MPPT Solar PCU, MICROTEK GT 125 KW, MICROTEK GT 1KW 1 kW Single Phase String On Grid Solar Inverter, Microtek Gt 2.2Kw (1Ph) Grid Tied Solar Pcu, MICROTEK GT 250KW (3PH), Microtek GT 3.3KW (1PH), Microtek HI-END MPPT 10070 / 120V, microtek mppt 3KVA / 48V, microtek mppt 5KVA / 48V, MICROTEK SCC 12v10a SOLAR CHARGE CONTROLLER, MICROTEK SCC 12v6a SOLAR CHARGE CONTROLLER, MICROTEK SMU 1012, MICROTEK SMU 3012, MICROTEK SMU 3024, Microtek Solar Grid Tie 50KW 3-PH- M32), Microtek Solar GT 40KW (3PH), Microtek Solar GT 60 KW, Microtek Solar On Grid Tied Inverter GT 4KW (1PH), Microtek Solar On Grid Tied Inverter GT 5KW (1PH.), Microtek Solar On Grid Tied Inverter GT 8.8KW (3PH.), Microtek SOLAR PV MODULE 100 Watt / 12V, Microtek SOLAR PV MODULE 165 Watt / 12V, Microtek SOLAR PV MODULE 270 Watt / 24V, Microtek SOLAR PV MODULE 330 Watt / 24V, Microtek SOLAR PV MODULE 330 Watt / 24V (DCR), Microtek SOLAR PV MODULE 50W 12V, Microtek SOLAR PV MODULE 75 Watt / 12V, Solar Grid Tie 11KW 3-PH -M32, Solar Grid Tie 20KW 3-PH- M32, Solar Grid Tie 30KW 3-PH- M32, Solar Grid Tie 5.5KW 3-PH- M32, Solar Grid Tie12KW 3-PH- M32, Solar Grid Tie15KW 3-PH- M32, SOLAR PCU 1235/12V, SOLAR PCU 1435/12V, Solar PCU 2035N / 24V, SOLAR PCU 2335/24V, Solar PCU 2350N / 24V, Solar PCU 2550 / 24V, Solar PCU 4050 / 48V, Solar PCU 6KVA / 48V, Solar PCU PWM/2350N/24V

Description
Reviews (0)

Description

Technical Specifications:

MODEL NO.	MTK3024 SMU
Max.Solar open circuit voltage(Voc)	40V
Max.Solar Panel Capacity	720Wp
Max.Battery Charging Current	30A
Peak Charger Efficiency	99%
System Voltage(V)	24VDC
Battery Full Voltage (Solar Charging)	29.0±0.4V
Battery Voltage (Mains Disconnect)	28.0±0.4V
Battery Voltage (Mains Reconnect)	23.0±0.4V
Recommended Battery Capacity	2x200AH
LCD Indications	Solar Charging, Panel Reverse, Battery Reverse, Output ON
Connection	TERMINAL BLOCK: For Solar Panel & Battery Connections MAINS IN: 1mm Power Cord With 16A Molded Plug Main Out: 15A Power Outlet
Front Panel Switch	NORMAL:Default Position, Solar Charging & Mains Control BYPASS: Solar Charging & Main Bypass

🏬 Available at:

SONI ENTERPRISES AND FOOTPRINT GROUP
📍 Shop No.13, Vidisha Rd, in front of Pashu Bazar, Bhanpur, Bhopal, Madhya Pradesh 462010
📞 Phone: 08839598197, 09993182145
📧 Email: premlalsonisoni@yahoo.in

📧 Email: Premlalsoni97@gmail.com
